FALL PROTECTION                                                                                                                                                                             FALL PROTECTION




              FALL PROTECTION LANYARDS


        BFD Bands                                        BFD LR Band             BFD Y Band
        • Standards: EN 354, EN 355:2002                 Art No.: 69162SK368     Art No.: 69162SK369
        • Suspension Element: Webbing
        • Material: Polyamide, Steel
        • Max. number of persons: 1
        • Max. service life: 4-6 Years
        • Hand-washing: 40 °C
        • Temperature: -35 °C to 50 °C
         Model                   BFD LR       BFD Y
         Length               1.5 m   2 m     1.5 m
         Weight               0.98 kg  1.01 kg  1.56 kg
         Carabiner on belt             FS 51 ST
         Carabiner - anchoring point   FS 90 ST







        Anchoring point  Shock absorber  Reinforced stitching
        SKYSAFE                                          SKYSAFE PRO Flex        SKYSAFE PRO Flex Y
        • Standards: EN 354, EN 355:2002                 Art No.: 69162SK461     Art No.: 69162SK462
        • Suspension Element: Webbing
        • Material: Polyamide, Steel
        • Max. service life: 4-6 Years
        • Max. number of persons: 1
        • Hand-washing: 40 °C
        • Temperature: -35 °C to 50 °C
         Model                   PRO Flex     PRO Flex Y
         Length                   1.8 m         1.8 m
         Weight                  1.55 kg        2.0 kg
         Carabiner on belt       STAK TRI     KOBRA TRI
         Carabiner - anchoring point  FS 92    FS 92 ST



                                                         • Energy absorber weight from 50-140kg (110-310 lbs.)
                                                         • Max. impact of less than 6 kN at min. length 1.75m (5.7’)
                                                         • Final impact resistant of 22 kN
        Anchoring point  Built-in rescue loops  Reinforced stitching
        PEANUT                                           PEANUT  I               PEANUT Y
        • Standards: EN 354, EN 360:2002, RFU CNB/P/11.060,  Art No.: 69162SK458  Art No.: 69162SK459
           RFU CNB/P/11.085
        • Max. Service Life: 10 Years
        • Max. number of persons: 1
        • Max. Rated Load: 135 kg
        • Suspension Element: Webbing
        • Material: Polyester, Polyamide, Steel
        • Temperature: from -35 °C to 45 °C
         Model                  Peanut I      Peanut Y
         Length                  1.8 m         1.8 m
         Weight                 1.75 kg        2.52 kg
         On the lanyard ends  SNAP HOOK 23kN  KOBRA TRI
         On the shock pack  SNAP HOOK 23kN    KOBRA TRI

                                   One-4-All
                                     SHOCK
                                   ABSORBER              • New One-4-All shock absorber and is therefore approved for the
                                                           weight class 50-135-kg. 1.8 m length for use in aerial work platforms.
        Anchoring point  Integrated vortex
