EYEWASH AND SAFETY SHOWERS
EMERGENCY EYEBATH AND FACEWASH
Wall or Pedestal Emergency Eye/Face Wash with Integral Lid
• High flow rate aerated diffusers provide an improved washing action and prevent
further injury to the eyes
• Integral lid connects to the water valve for automatic operation when the lid is
pulled down. The lid also ensures that the bowl remains clean and free from
contamination at all times
• Flow regulator valve ensures an optimum water flow
• The pedestal mounted range of emergency eye/face wash units includes
freeze protected and self-draining models, ideal for challenging environments
• Optional fittings available
Specification
Eye/Facewash Bowl/Lid Closed ABS bowl
Depth 362 mm
Width 320 mm
Height 227 mm
Art No: STD-45G
Nominal Weight 3 kg
Inlet Size 1/2 in (F) BSP Art No: STD-45G/P
Min Pressure 2 kg/cm2 Art No: STD-45S/P
Water Flow 12 Litres per min.
*Models available in Galvanized Mild Steel or Stainless Steel
Outdoor Emergency Eye/Facewash
• Has high flow rate aerated diffusers for improved washing action to the
eyes, face and hands and incorporates an integral lid connected to the
water valve for automatic operation when the lid is lifted
• Trace tape heated and pre-insulated
• Incorporating an integral lid and an additional Eyebath diffuser on flexible hose
• Optional fittings available
Specification
Water Inlet 1 ¼” Male BSP
Test Pressure 10.3 BAR G
Min. Flow Rates Eye/Facewash: 20 Litres/mins
Eyebath: 8 Litres/mins
Operating Pressure 2.2 to 6 BAR G
Activation Lift Lid
Art No: STD-H-25K/P
Dimension 475(W) x 720(D) x 1130 (H) mm
Weight When Full 20 kg
Ceiling Mounted Safety Shower
• Unheated Ceiling Mounted Emergency Safety Shower with
mounting plate.
• Operated by a pull handle for ease of use in an emergency
• Has a removable self-draining overhead shower head, which is
specifically designed for high flow rates in line with ANSI and
EUstandards
• Optional fittings available Art No: EXP-23G/V Art No: EXP-23GS/V
Specification
Depth 175 mm
Width 228 mm
Height 801 mm
Nominal Weight 4 kg
Inlet Size 1in (F) BSP
Min Pressure 1.5 kg/cm2
Water Flow 76 shower *Models available in Galvanized Mild Steel or Stainless Steel
