EYEWASH AND SAFETY SHOWERS                                                                                                                                             EYEWASH AND SAFETY SHOWERS




        EMERGENCY TANK SHOWERS

        General Use Tank Shower With Chiller
        Art No. EXP-J-14K/1500
        • Designed to meet and exceed ANSI and European standards by                               Meet and exceed
          providing tepid water for over 15 minutes at a guaranteed flow
          of 76 litres (20 US gallons) per minute, even when there is no                  ANSI and European standards
          water supply.                                                                  by providing tepid water for over
        • Available in 350 or 1500 litre capacities, the emergency tank                15 minutes at a guaranteed flow of
          showers are activated using the panic bar or optional foot panel.            76 litres (20 US gallons) per minute,
        • Available with either galvanized mild steel or stainless steel frames
        • Optional eye/face wash unit can be mounted internally or                              even when there is no
          externally                                                                             mains water supply.


         Specification
         Depth                         1495 mm
         Width                         1420 mm
                                                                                        Non-Flameproof Chiller
         Height                        3746 mm
         Nominal Weight                 340 kg
         Inlet Size                   3/4 in (F) BSP
         Min Pressure                  0.5 kg/cm2
         Water Flow                    76 shower
                                     12 eye/face wash
                                                                                                     Flameproof
        Model also available in:                                                                     Chiller
        - EXP-J-14K/350
        - EXP-J-14K/1500






        General Use Tank Shower
        Art No. EXP-J-14K/1500
        • An insulated 1500 litre tank with rectangular hollow section frame             Lifting lugs
        • The outdoor types are heated and pre-insulated to prevent
          freezing during conditions of frost, whereas the indoor or tropical            Visual level indicator (Optional)
          versions are insulated but without the heating to ensure a steady
          temperature is maintained.
        • Available with either galvanized mild steel or stainless steel frames          Sign and light box
        • Optional eye/face wash unit can be mounted internally or
          externally


         Specification
                                                                                         Indicator light
         Depth                         1495 mm
                                                                                         GRP outer
         Width                         1420 mm
         Height                        3746 mm
         Nominal Weight                 340 kg                                           Eye/Facewash fountain
         Inlet Size                   3/4 in (F) BSP
                                                                                         Shower test
         Min Pressure                  0.5 kg/cm2
         Water Flow                    76 shower
                                     12 eye/face wash                                    Shower control panic bar

        Model also available in:                                                         Drain pipe
        - EXP-J-14K/350
        - EXP-J-14K/1500
                                                                                         Foot panel (Optional)
